Engine Air Filter

November 8, 2023

1. What is an engine air filter?

The engine air filter is a rectangular or square shaped rubber, plastic or cardboard frame that contains a pleated paper accordion. The paper has fiber or cloth filaments to help prevent contaminants from penetrating it's surface. The contaminants are dust, dirt, road debris, insects and other air borne material from entering the engine’s combustion chamber and intake manifold.


2. How does it work?

It works by filtering the air going into the engine intake manifold. The paper accordion traps contaminants from entering the engine. These contaminants are dust, dirt, pollen, bugs, leaves, other foliage and debris that floats in our surface air.


3. What happens if I drive with a dirty or clogged filter?

It has been suggested it may negatively affect the cars gas mileage. Recent tests have disproved this theory as modern fuel controls adapt well. What does happen is the engine performance is reduced. When the intake manifold received less air due to a dirty engine air filter the fuel system computer cuts back on the amount of fuel sent to the manifold. This reduction varies amongst different car manufacturers and models. But overall the power (acceleration) could be reduced by almost 15% in some models.


4. How often should the air filter be replaced?

Annually we suggest the engine air filter be checked and replaced if dirty. If the car is not driven the national average of 12,000 miles a year, the filter may be OK. If the car is driven in areas with a lot of dust, pollen, smoke or other air born debris the filter will likely get dirtier quicker and have to be change more frequently. But regardless of the miles driven the engine air filter should be examined annually.


5. Is it hard to replace an air filter?

Generally speaking, no, the air filter is usually on top of the engine and access is relatively easy. It does not require special tools but the air filter housing is usually sealed with rubber gaskets and held together with screws or plastic clips. The clips can be brittle due to heat transfer from the engine and can break easily.
